| Color/Finish |
| Size/Weight |
| Dimensions |
Width |
992 mm (39-1/16”) |
| Height |
136 mm (5-3/8”) |
| Depth |
404 mm (15-7/8”) |
| Weight |
Weight |
7.0 kg (15 lb, 7 oz) (not including batteries) |
| Control Interface |
| Keyboard |
Number of Keys |
61 |
| Touch Response |
Yes (Soft, Medium, Hard, Fixed) |
| Type |
Organ-style |
| Other Controllers |
Pitch Bend |
Yes |
| Art. Switches |
Yes |
| Control Knobs |
2 |
| Display |
Type |
LCD |
| Backlight |
Yes |
| Panel |
Language |
English |
| Voices |
| Tone Generation |
Tone Generating Technology |
AWM Stereo Sampling |
| Polyphony |
Number of Polyphony (Max.) |
64 |
| Preset |
Number of Voices |
820 (294 Panel Voices + 28 Drum/SFX kits + 40 Arpeggio + 458 XGlite Voices) |
| Featured Voices |
3 Live! Voices, 9 Sweet! Voices, 6 Cool! Voices, 14 Super Articulation Lite Voices |
| Compatibility |
GM |
Yes |
| XGlite |
Yes |
| Effects |
| Types |
DSP |
DSP1: 41 types, DSP2: 12 types |
| Reverb |
12 types |
| Chorus |
5 types |
| Master EQ |
4 types |
| Functions |
Dual/Layers |
Yes |
| Split |
Yes |
| Melody Suppressor |
Yes (w/ pan adjustment) |
| Crossfade |
Yes (between Internal Sound and External Audio) |
| Accompaniment Styles |
| Preset |
Number of Preset Styles |
290 |
| Fingering |
Multi finger, Smart Chord |
| Style Control |
ACMP ON/OFF, SYNC START, SYNC STOP, START/STOP, INTRO/ENDING/rit., MAIN/AUTO FILL, TRACK ON/OFF |
| Other Features |
One Touch Setting (OTS) |
Yes |
| Expandability |
Expansion Style |
10 |
| Compatibility |
Style File Format (SFF) |
| Groove Creator |
| Preset |
Number of Groove |
35 |
| Number of Sections |
5 (4 Sections + 1 Musical Climax/Ending) |
| Songs |
| Preset |
Number of Preset Songs |
30 |
| Recording |
Number of Songs |
10 |
| Number of Tracks |
6 (5 Melody + 1 Style/Groove Creator) |
| Data Capacity |
Approx. 19,000 notes (when only “melody” tracks are recorded) |
| Compatible Data Format |
Playback |
SMF (Formats 0 & 1) |
| Recording |
Original File Format (SMF 0 conversion function) |
| USB Audio Recorder |
| Recording Time (max.) |
80 minutes (approx. 0.9 GB) per Song |
| Format |
Playback |
WAV (44.1 kHz, 16 bit, stereo) |
| Recording |
WAV (44.1 kHz, 16 bit, stereo) |
| Quick Sampling |
| Sampling Type |
One-shot, Loop |
| Samples (Preset/User) |
4 |
| Sampling Time |
Approx. 9.6 sec |
| Sampling Sources |
AUX IN, MIC INPUT, USB audio interface, WAV format files |
| Sampling Format |
Original File Format (16 bit, stereo) |
| Sampling Rate |
44.1 kHz |
| Functions |
| USB audio interface |
44.1 kHz, 16 bit, stereo |
| Registration |
Number of Buttons |
4 (x 8 banks) |
| Control |
Freeze |
| Overall Controls |
Metronome |
Yes |
| Tempo Range |
11 – 280 |
| Transpose |
-12 to 0, 0 to +12 |
| Tuning |
427.0 – 440.0 – 453.0 Hz (approx. 0.2 Hz increments) |
| Octave Button |
Yes |
| Scale Type |
5 types |
| Miscellaneous |
PIANO Button |
Yes (Portable Grand Button) |
| Other Functions |
Mega Boost, Motion Effect (57 types) |
| Voices |
Harmony/Echo |
26 types |
| Arpeggio |
152 types |
| Storage and Connectivity |
| Storage |
Internal Memory |
Approx. 1.72 MB |
| External Drives |
USB flash drive |
| Connectivity |
DC IN |
12 V |
| AUX IN |
Stereo mini jack x 1 |
| Headphones |
Standard stereo phone jack x 1 |
| Sustain Pedal |
Yes |
| USB TO DEVICE |
Yes |
| USB TO HOST |
Yes |
| OUTPUT |
Standard phone jack x 2 |
| Microphone |
Standard phone jack x 1 |
| Amplifiers and Speakers |
| Amplifiers |
6 W + 6 W |
| Speakers |
12 cm x 2 |
| Power Supply |
| Power Supply |
AC Adaptor PA-150 or an equivalent recommended by Yamaha, or six “AA” size alkaline (LR6), manganese (R6) or Ni-MH rechargeable (HR6) batteries |
| Power Consumption |
9 W (When using PA-150 AC adaptor) |
| Auto Power Off Function |
Off/5/10/15/30/60/120 (minutes) |
| Accessories |
| Included Accessories |
Music Rest |
Yes |
| Song Book |
Download from Yamaha web site |
