Euphonycart Presents, Boss FDR 1 Guitar Stomp Pedal
The second in the new Legend Series is the FDR-1, based on the Fender 1965-era Deluxe Reverb — a coveted tube amp known for its natural touch-responsive and distinctive snappy overdriven sound. In conjunction with Fender, BOSS designed this stompbox to recreate the legendary tone of the 1965 Fender Deluxe Reverb amp. Features include the same controls on the original Deluxe Reverb: Level, Gain, Treble, Bass, Vibrato and Reverb. The FDR-1 also functions perfectly as a “pre-gain pedal” placed before an already overdriven amp to add the tone character of the Deluxe Reverb.
Specification
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 2.2 k ohms
- Recommended Load Impedance
- 10 k ohms or greater
- Controls
- Pedal switch, GAIN knob, LEVEL knob, TREBLE knob, BASS knob, VIBRATO knob, REVERB knob
- Indicator
- CHECK indicator (Serves also as battery check indicator)
- Connectors
- INPUT jack, OUTPUT jack, AC adaptor jack (DC 9 V)
- Power Supply
- DC 9 V, Dry battery 6F22 (9 V) type (carbon), Dry battery 6LR61 (9 V) type (alkaline), AC Adaptor (PSA series: optional)
- Current Draw
- 40 mA (DC 9 V)
- Expected battery life under continuous use
- Carbon: 2.7 hours, Alkaline: 9 hours * These figures will vary depending on the actual conditions of use.
- Accessories
- Owner’s Manual, Leaflet (USING THE UNIT SAFELY, IMPORTANT NOTES, and Information), Dry Battery 006P/9V (6LR61)
- Options
- AC Adaptor (PSA series)
- SIZE AND WEIGHT
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight
- 440 g
1 lbs.
