Description
- Next-generation guitar compressor that uses BOSS’s advanced MDP tech to preserve musical expression
- Intelligent circuitry adapts to every register and playing nuance, providing natural compression with exceptional clarity
- Sophisticated under-the-hood processing with multiple interlocking parameters, accessible with simple stompbox controls
- Gain reduction indicator shows the current compression amount at a glance
- Digital circuitry greatly reduces noise, a common problem with standard compressors
- Professional 18-volt input electronics provide ample headroom for clean, punchy sound
- Works with all types of guitars, including seven- and eight-string instruments and acoustic-electrics
- BOSS five-year warranty
- SPECIFICATIONS
- Nominal Input Level
- -20 dBu
- Input Impedance
- 1 M ohm
- Nominal Output Level
- -20 dBu
- Output Impedance
- 1 k ohm
- Recommended Load Impedance
- 10 k ohms or greater
- Bypass
- Buffered bypass
- Controls
- Pedal switch
COMP knob
RATIO knob
ATTACK knob
LEVEL knob - Indicators
- CHECK indicator (Serves also as battery check indicator)
GAIN REDUCTION indicator - Connectors
- INPUT jack
OUTPUT jack
DC IN jack - Power Supply
- Alkaline battery (9V, 6LR61)
AC adaptor (sold separately) - Working Voltage
- 18 V
- Current Draw
- 90 mA
- Expected battery life under continuous use
- Alkaline: Approx. 3 hours
* These figures will vary depending on the actual conditions of use. - Accessories
- Owner’s Manual
Leaflet (“USING THE UNIT SAFELY,” “IMPORTANT NOTES,” and “Information”)
Alkaline battery (9V, 6LR61) - Option (sold separately)
- AC adaptor (PSA series)
- SIZE AND WEIGHT
- Width
- 73 mm
2-7/8 inches - Depth
- 129 mm
5-1/8 inches - Height
- 59 mm
2-3/8 inches - Weight (including battery)
- 450 g
1 lb - * 0 dBu = 0.775 Vrms
